15
The One-Touch feature must be enabled in the Digiplex control panel to use this feature. See the appropriate Digiplex
control panel’s Reference and Installation Manual for more information.
Area Disarm
The following commands disarm areas. For the panel’s maximum number of areas, refer to “Panel Specifications” on page 1.
* xxxxxx represents the code used to arm the system. If the code is shorter than six digits, enter only the appropriate amount of digits.
If an invalid user code is entered, the command will be returned followed by “&fail”.
Emergency Panic
The following commands are used for emergency panic alarms in up to eight areas. For the panel’s maximum number of areas, refer to
“Panel Specifications” on page 1.
Panic alarms must be individually enabled. See the appropriate Digiplex control panel’s Reference and Installation Manual
for more information.
Medical Panic
The following commands are used for medical panic alarms in up to eight areas. For the panel’s maximum number of areas, refer to “Panel
Specifications” on page 1.
Panic alarms must be individually enabled. See the appropriate Digiplex control panel’s Reference and Installation Manual
for more information.
Quick Arm Area 02
AQ002
A (Regular
arm)
F (Force arm)
S (stay arm)
I (Instant arm
<cr>
LL
Quick Arm Area 08
AQ008
A (Regular
arm)
F (Force arm)
S (stay arm)
I (Instant arm
<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Bytes 6-11 Byte 12
Disarm Area 01
A D 0 0 1 xxxxxx* <cr>
Disarm Area 02
AD002“<cr>
LL
Disarm Area 08
AD008“<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Panic 1 - Emergency Area 01
P E 0 0 1 <cr>
Panic 1 - Emergency Area 02
P E 0 0 2 <cr>
LL
Panic 1 - Emergency Area 08
P E 0 0 8 <cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Panic 2 - Medical Area 01
P M 0 0 1 <cr>
Panic 2 - Medical Area 02
P M 0 0 2 <cr>
LL
Panic 2 - Medical Area 08
P M 0 0 8 <cr>
