14
Request Area Label
The following commands request the area label. For the panel’s maximum number of areas, refer to “Panel Specifications” on page 1.
The Request Area Label command also involves an information request. When the command is valid, the first five characters of the
command are returned followed by the requested area label. All area labels are 16 characters in length.
Request User Label
The following commands request the user label. For the panel’s maximum number of users, refer to “Panel Specifications” on page 1.
The Request User Label command also involves an information request. When the command is valid, the first five characters of the
command are returned followed by the requested user label. All user labels are 16 characters in length.
Area Arm
The following commands arm areas. For the panel’s maximum number of areas, refer to “Panel Specifications” on page 1.
* xxxxxx represents the code used to arm the system. If the code is shorter than six digits, enter only the appropriate amount of digits.
If an invalid user code is entered, the command will be returned followed by “&fail”.
Area Quick Arm
The following commands quick arm areas. For the panel’s maximum number of areas, refer to “Panel Specifications” on page 1.
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Request Area Label 01
AL001<cr>
Request Area Label 02
AL002<cr>
LL
Request Area Label 08
AL008<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Request User Label 01
UL001<cr>
Request User Label 02
UL002<cr>
LL
Request User Label 999
UL999<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Bytes 7-12 Byte 13
Arm Area 01
AA001
A (Regular
arm)
F (Force arm)
S (stay arm)
I (Instant arm)
xxxxxx* <cr>
Arm Area 02
A A 0 0 2 “ “ <cr>
LL
Arm Area 08
A A 0 0 8 “ “ <cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
Quick Arm Area 01
AQ001
A (Regular
arm)
F (Force arm)
S (stay arm)
I (Instant
arm)
<cr>
