Appendix 1: Programming PGMS
A PGM is a programmable output that toggles to its opposite state (i.e. a normally open PGM will close) when a specific event occurs in the
system. For example, a PGM can be used to reset smoke detectors, activate strobe lights, open/close garage doors and much more.
PGM Activation Event
The PGM Activation Event determines which event from which source will activate the PGM. The Event Group specifies the event, the
Feature Group identifies the source, and the Start # and End # sets the range within the Feature Group (see PGM Programming Table
below).
For example, the PRT3 can activate Virtual PGM1 when the area is armed by User Access Codes 256 to 260. Therefore:
Event Group section [102] = 010 “Arming with User Code”
Feature Group section [103] = 001 “User Codes 256 to 511”
Start # section [104] = 000 (representing user code 256)
End # section [105] = 004 (representing user code 260)
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the desired PGM and enter the data as required.
PGM Deactivation Option
Once the PGMs are activated, they can deactivate when another event occurs or after a period of time. The PGM Deactivation Option
determines which method is used, the PGM Deactivation Event or the PGM Timer. Enter the section that corresponds to the desired PGM
and enable or disable the option.
PGM Deactivation Event
When the PGM Deactivation Option (see above) is disabled, the PGM Deactivation Event determines which event from which source will
return the PGM to its original state. The Event Group specifies the event, the Feature Group identifies the source, and the Start # and End #
determine the range within the Feature Group. The complete PGM Programming Table appears below.
For example, the PRT3 can deactivate Virtual PGM1 when zone 3 opens. Therefore:
Event Group section [106] = 001 “Zone is Open”
Feature Group section [107] = 000 “Zone Numbers”
Start # section [108] = 003
End # section [109] = 003
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the desired PGM and enter the data as required.
PGM Programming Table
Event Group Feature Group Start # End #
PGM Activation
Event
PGM __/__/__ __/__/__ __/__/__ __/__/__
PGM Deactivation
Event
PGM __/__/__ __/__/__ __/__/__ __/__/__
Event
Group
Event Feature Group Feature Start # End #
000 Zone is OK
000 Zone Numbers 001 to 192 001 to 192
255 Any zone number Not Used Not Used
001 Zone is Open
000 Zone Numbers 001 to 192 001 to 192
255 Any zone number Not Used Not Used
002 Zone is Tampered
000 Zone Numbers 001 to 192 001 to 192
255 Any zone number Not Used Not Used
To Next Page
