NVX80 Installation Manual 33
Appendix 3: Technical Specifications
SeeTrue™ Effective Range Indoor use, two levels, secure and sterile, up to 12 m (36 ft)
Dual Anti-Mask Selectable:
1) Active IR: Proximity and blocking c
omply / surpass EN50131 grade 3 for all
materials, liquids.
2) Active Microwave for movement detection.
Creep Zone Area Up to 3 m (10 ft) 90° downward
Coverage Pattern
16m (52 ft) 90°
Installation Height 2.5 - 3.0m (8 - 10 ft). A bracket may be used for installation requiring higher
mounting.
Current Consumption
(at 12V)
Typ. 80 mA, max. 100 mA
Outputs Relay 1: 1A 24 VDC
Relay 2 and 3: 150 mA / 24 VDC
Display
OLED, 16-bit, 96 x 64 pixels
Dimensions 9.8 cm x 22.9 cm x 9.2 cm (3.8 in x 9.0 in x 3.6 in)
Tamper
Dual : Cover and Wall
RF Immunity 10 V/m up to 2.7 GHz
Operating Temperature
-35º to 60º C (-31º to 140º F)
Bus Connection Paradox EVO Series, 4 wires
Certification
EN 50131 Grade 3 Class IV
Construction Materials ASA UV Resistant
Programming
Interactive 4-button programming with graphic menu display or via EVO bus
Weight 520 g (1.1 lb)
PIR Forward
2X quad sensors with interlock geometry
PIR Creep 1X quad sensor with interlock geometry
Microwave
Dual output 10.5 GHz
Power Up Time Approximately 30 seconds
Humidity
5 - 95% RH non-condensing
Ingress Protection (IP) Rating IP54 & IP55 (dust and water protection)
Pet Immunity
Suppress detection of animals: Settings for small and large pets
Languages English, Portuguese
