Paradox SP5500+ User Manual

15
Custom Zone Definitions
With SP+ Series control panels you can create up to four custom zone definition templates (use worksheet 8). Custom zone definition templates (sections [033] to [036]) will overwrite zone definitions 33 to 36 in
table 4 on page 13. Modifications can be made in accordance with table 8 (Permitted zone definitions), on page 14.
Zone Timers
Use the following section to program zone timers for your SP+ Series control panels. Use worksheets 9 and 10 to record your settings.
NOTE: When both ATZ (SP6000+ only) and EOL are enabled, the zone speed should not be set below 300 msec.
Worksheet 9: Timers
Worksheet 8: Custom Zone Definitions
Section Description Disarm Stay Arm Sleep Arm Full Arm
[033] Zone definition template 1 _____/_____ _____/_____ _____/_____ _____/_____
[034] Zone definition template 2 _____/_____ _____/_____ _____/_____ _____/_____
[035] Zone definition template 3 _____/_____ _____/_____ _____/_____ _____/_____
[036] Zone definition template 4 _____/_____ _____/_____ _____/_____ _____/_____
Section Zone SP5500+ SP6000+ SP7000+ Data Description (default: 060)
[041] 1 (Z1) (Z1) (Z1) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 1
[042] 2 (Z2) (Z2) (Z2) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 2
[043] 3 (Z3) (Z3) (Z3) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 3
[044] 4 (Z4) (Z4) (Z4) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 4
[045] 5 (Z5) (Z5) (Z5) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 5
[046] 6 (Z6) (Z6) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 6
[047] 7 (Z7) (Z7) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 7
[048] 8 (Z8) (Z8) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 8
[049] 9 (Z1 ATZ) (Z9) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 9
[050] 10 (Z2 ATZ) (Z10) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 10
[051] 11 (Z3 ATZ) (Z11) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 11
[052] 12 (Z4 ATZ) (Z12) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 12
[053] 13 (Z5 ATZ) (Z13) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 13
[054] 14 (Z6 ATZ) (Z14) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 14
[055] 15 (Z7 ATZ) (Z15) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 15
[056] 16 (Z8 ATZ) (Z16) ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 16

Paradox SP5500+ Specifications

General

StayD Mode	Yes
PGMs	4 programmable outputs
Partitions	2 partitions
Expandable via Bus	Yes
Outputs	4 programmable outputs
Power Supply	1.5A
Battery Backup	7Ah
