SP+ Series Programming Guide
29
Wireless Repeater Programming (RPT1/RPT1+)
Use the following section to program the wireless repeaters on your SP+ Series control panel.
Wireless Repeater Assignment
Use worksheet 22 to record your settings when assigning wireless repeaters to your SP+ Series control panel. To reset wireless repeaters, see Description of Section
[965] on page 52.
NOTE: For automatic assignment, press the wireless repeater’s anti-tamper switch, while in the repeater’s respective section.
Wireless Repeater Signal Strength
The signal strength for wireless repeaters is visible in sections [548] and [549]; these sections represent repeaters 1 and 2, respectively. To view the signal strength,
proceed as follows:
1. Enter the wireless repeater’s respective section (e.g., for repeater 1, enter section [548]).
2. Press the repeater’s anti-tamper switch. As shown in table 16, the number of beeps correspond to a preset signal strength range.
NOTE: The visual representation of a repeater’s signal strength is dependent on the type of keypad. For LED keypads, zones 1 through 10 will illuminate, depending
on the signal strength. For instance, a signal strength of 8 will result in zones 1 through 8 to illuminate. For LCD keypads, a ten-level progress bar composed of
arrows will appear, followed by the numeric value. For a signal strength of 8, eight arrows will appear, followed by the number 8.
Worksheet 22: Wireless Repeater Assignment
Section Description Wireless Repeater Serial Number
[545] Repeater 1 ___/___/___/___/___/___
[546] Repeater 2 ___/___/___/___/___/___
Table 16: Signal strength indicator for wireless repeaters
Number of Beeps Signal Strength Result
3 8 to 10 Strong signal
2 5 to 7 Average signal
1 1 to 4 Weak signal (relocate)
