Paradox SP5500+ User Manual

24
SP+ Series Programming Guide
PGM Activation/Deactivation Events
Use worksheet 14 to record your settings for the SP+ Series PGM events. See table 10 on page 18, for a list of these events.
* Section [220], PGM 1 activation event: default = option B remote assignment. Button pressed on any remote/any partition (see table 21 on page 33).
** Section [222], PGM 2 activation event: default = option C remote assignment. Button pressed on any remote/any partition (see table 21 on page 33).
57 Non-medical alarm (paramedic)
01 to 32 User number
99 Any user number
58 Zone forced
01 to 32 Zone number
99 Any zone number
59
Zone included
01 to 32 Zone number
Zone included (Cont.)
99 Any zone number
60 Remote low battery
01 to 32 User number
99 Any user number
61 Remote low battery restore
01 to 32 User number
99 Any user number
64 System status (on-board PGMs only) 00
Follow
ARM LED status*:
PGM pulse fast in alarm
PGM pulse fast in exit delay, below 10 sec.
PGM pulse slow in exit delay, over 10 sec.
PGM steady ON, if armed
PGM OFF, if disarmed
* This event can be assigned to partition 1 or 2. If assigned to
both partitions, the PGM event will follow the list order above,
with number 1 being the highest priority.
Worksheet 14: PGM Activation/Deactivation Events
Section PGM Event Event Group Sub-group
Partition
(99 for both)
Default Section PGM Event Event Group Sub-group
Partition
(99 for both)
Default
[220]
PGM 1
Activation ___/___ ___/___ ___/___ 08/99/99* [236]
PGM 9
Activation ___/___ ___/___ ___/___ 00/00/00
[221] Deactivation ___/___ ___/___ ___/___ 00/00/00 [237] Deactivation ___/___ ___/___ ___/___ 00/00/00
[222]
PGM 2
Activation ___/___ ___/___ ___/___ 09/99/99** [238]
PGM 10
Activation ___/___ ___/___ ___/___ 00/00/00
[223] Deactivation ___/___ ___/___ ___/___ 00/00/00 [239] Deactivation ___/___ ___/___ ___/___ 00/00/00
[224]
PGM 3
Activation ___/___ ___/___ ___/___ 00/00/00 [240]
PGM 11
Activation ___/___ ___/___ ___/___ 00/00/00
[225] Deactivation ___/___ ___/___ ___/___ 00/00/00 [241] Deactivation ___/___ ___/___ ___/___ 00/00/00
[226]
PGM 4
Activation ___/___ ___/___ ___/___ 00/00/00 [242]
PGM 12
Activation ___/___ ___/___ ___/___ 00/00/00
[227] Deactivation ___/___ ___/___ ___/___ 00/00/00 [243] Deactivation ___/___ ___/___ ___/___ 00/00/00
[228]
PGM 5
Activation ___/___ ___/___ ___/___ 00/00/00 [244]
PGM 13
Activation ___/___ ___/___ ___/___ 08/99/01
[229] Deactivation ___/___ ___/___ ___/___ 00/00/00 [245] Deactivation ___/___ ___/___ ___/___ 08/99/01
[230]
PGM 6
Activation ___/___ ___/___ ___/___ 00/00/00 [246]
PGM 14
Activation ___/___ ___/___ ___/___ 09/99/01
[231] Deactivation ___/___ ___/___ ___/___ 00/00/00 [247] Deactivation ___/___ ___/___ ___/___ 09/99/01
[232]
PGM 7
Activation ___/___ ___/___ ___/___ 00/00/00 [248]
PGM 15
Activation ___/___ ___/___ ___/___ 00/00/00
[233] Deactivation ___/___ ___/___ ___/___ 00/00/00 [249] Deactivation ___/___ ___/___ ___/___ 00/00/00
[234]
PGM 8
Activation ___/___ ___/___ ___/___ 00/00/00 [250]
PGM 16
Activation ___/___ ___/___ ___/___ 00/00/00
[235] Deactivation ___/___ ___/___ ___/___ 00/00/00 [251] Deactivation ___/___ ___/___ ___/___ 00/00/00
Table 10: List of events
Event Group Event Group Description Sub-group Sub-group Description
