SP+ Series Programming Guide
25
PGM Options
1
If a PGM delay is programmed (OFF option), the deactivation event can be used as a second activation event.
Section [277] for SP5500+ / SP6000+
Section [277] for SP7000+
Table 11: Description of PGM options
Option Description
PGM 1 [261] PGM 2 [262] PGM 3 [263] PGM 4 [264] PGM 5 [265] PGM 6 [266] PGM 7 [267] PGM 8 [268]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 PGM base time (OFF = sec., ON = min.)
2 PGM state (OFF = N.O.; ON = N.C.)
3 PGM supervision
4
PGM activation mode
(OFF = steady; ON = pulse)
5 PGM pulse once every 30 seconds, if armed
6 PGM pulse on any alarm
7
PGM pulse on any alarm (OFF = partition 1;
ON = partition 2)
8
Flexible PGM deactivation option
(OFF
1
= PGM delay only, two activation
events; ON = PGM delay or deactivation
event, whichever comes first)
Option Description
PGM 9 [269] PGM 10 [270] PGM 11 [271] PGM 12 [272] PGM 13 [273] PGM 14 [274] PGM 15 [275] PGM 16 [276]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 PGM base time (OFF = sec., ON = min.)
2 PGM state (OFF = N.O.; ON = N.C.)
3 PGM supervision
4
PGM activation mode (OFF = steady;
ON = pulse)
5 PGM pulse once every 30 seconds, if armed
6 PGM pulse on any alarm
7
PGM pulse on any alarm (OFF = partition 1;
ON = partition 2)
8
Flexible PGM deactivation option
(OFF
1
= PGM delay only, two activation
events; ON = PGM delay or deactivation
event, whichever comes first)
= Default Setting
Table 12: Description of section [277] for SP5500+ / SP6000+
Option Option Type Description
[277]
OFF ON
1
Voltage output
(OFF = negative trigger, 0V;
ON = positive trigger, 12V)
PGM 1
2PGM 2
3PGM 3
= Default Setting
Table 13: Description of section [277] for SP7000+
Option Option Type Description
[277]
OFF ON
1
Voltage output
(OFF = negative trigger, 0V;
ON = positive trigger, 12V)
PGM 1
l
2PGM 2
l
3PGM 3
l
4PGM 4
l
= Default Setting
