Zone Labels
Use worksheet 12 to record your settings when programming zone labels.
Programmable Output Programming
Use the following section to program programmable outputs (PGMs) on your SP+ Series control panel.
Programmable Output Recognition
Worksheet 13: Programmable outputs for SP+ Series control panels
NOTE: A wireless PGM module can be assigned to any PGM. These modules will work in parallel with the control panel output.
Programmable Output on the K32LCD/K32LX
The on-board PGM of the K32LCD and K32LX (not programmable) will follow the arm status of any partition, via any arming method, including StayD.
Worksheet 12: Zone Labels
Section Zone Zone Label Section Zone Zone Label
[181]
1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[197]
17 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[182]
2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[198]
18 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[183]
3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[199]
19 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[184]
4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[200]
20 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[185]
5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[201]
21 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[186]
6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[202]
22 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[187]
7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[203]
23 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[188]
8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[204]
24 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[189]
9 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[205]
25 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[190]
10 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[206]
26 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[191]
11 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[207]
27 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[192]
12 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[208]
28 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[193]
13 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[209]
29 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[194]
14 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[210]
30 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[195]
15 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[211]
31 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[196]
16 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[212]
32 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
PGM PGM Output
Control Panel
SP5500+ SP6000+ SP7000+
1 Control panel output 1 
2 Control panel output 2 
3 Control panel output 3 - Optional 
4 Control panel output 4 - Optional 
5 Control panel relay - Optional 
6 ZX8/ZX82 ID = 1 output 
7 ZX8/ZX82 ID = 2 output 
8 ZX8/ZX82 ID = 3 output  -
9PGM4/PGM82 relay 1 
10 PGM4 /PGM82 relay 2 
11 PGM4/PGM82 relay 3 
12 PGM4/PGM82 relay 4 
13 RTX3/RX1 output 1 
14 RTX3/RX1 output 2 
15 RTX3 output 3 (relay) 
16 RTX3 output 4 (relay) Optional Optional Optional

Paradox SP5500+ Specifications

General

StayD Mode	Yes
PGMs	4 programmable outputs
Partitions	2 partitions
Expandable via Bus	Yes
Outputs	4 programmable outputs
Power Supply	1.5A
Battery Backup	7Ah
