SP+ Series Programming Guide
Wireless Zone Assignment
Use the following section to program the wireless zones on your SP+ Series control panels. Use worksheet 10 to record your settings.
NOTE: When assigning wireless zones, enter the serial number, or press
TAMPER/LEARN; for the 2WPGM, remove and re-install Jumper 2 (JP2). To delete the serial
number, enter 000000.
Wireless Transmitter Signal Strength
The signal strength test for wireless transmitters is performed in sections [101] to [132]; these sections represent zones 1 to 32, respectively. To test the wireless
transmitter strength of your various wireless devices, proceed as follows:
1. Enter the zone’s respective section (e.g., for zone 1, enter section [101]).
2. For all wireless transmitters except 2WPGM: Press the transmitter’s anti-tamper switch and note the number of beeps which are emitted. As shown in table 9,
the number of beeps correspond to a preset signal strength range.
For the 2WPGM: Remove and re-install Jumper 2 (JP2).
NOTE: The visual representation of a transmitter’s signal strength is dependent on the type of keypad. For LED keypads, zones 1 through 10 will illuminate,
depending on the signal strength. For instance, a signal strength of 8 will result in zones 1 through 8 to illuminate. For LCD keypads, a ten-level progress bar
composed of arrows will appear, followed by the numeric value. For a signal strength of 8, eight arrows will appear, followed by the number 8.
Zone Report Codes and Labels
Use the following section to program zone report codes and labels on your SP+ Series control panels.
Zone Report Codes
Use worksheet 11 to record your settings when programming zone report codes.
Worksheet 10: Wireless Zones
Section Zone Wireless Zone (Serial #) Section Zone Wireless Zone (Serial #) Section Zone Wireless Zone (Serial #)
[061] 1 ___/___/___/___/___/___ [072] 12 ___/___/___/___/___/___ [083] 23 ___/___/___/___/___/___
[062] 2 ___/___/___/___/___/___ [073] 13 ___/___/___/___/___/___ [084] 24 ___/___/___/___/___/___
[063] 3 ___/___/___/___/___/___ [074] 14 ___/___/___/___/___/___ [085] 25 ___/___/___/___/___/___
[064] 4 ___/___/___/___/___/___ [075] 15 ___/___/___/___/___/___ [086] 26 ___/___/___/___/___/___
[065] 5 ___/___/___/___/___/___ [076] 16 ___/___/___/___/___/___ [087] 27 ___/___/___/___/___/___
[066] 6 ___/___/___/___/___/___ [077] 17 ___/___/___/___/___/___ [088] 28 ___/___/___/___/___/___
[067] 7 ___/___/___/___/___/___ [078] 18 ___/___/___/___/___/___ [089] 29 ___/___/___/___/___/___
[068] 8 ___/___/___/___/___/___ [079] 19 ___/___/___/___/___/___ [090] 30 ___/___/___/___/___/___
[069] 9 ___/___/___/___/___/___ [080] 20 ___/___/___/___/___/___ [091] 31 ___/___/___/___/___/___
[070] 10 ___/___/___/___/___/___ [081] 21 ___/___/___/___/___/___ [092] 32 ___/___/___/___/___/___
[071] 11 ___/___/___/___/___/___ [082] 22 ___/___/___/___/___/___
Table 9: Signal strength indicator for wireless transmitters
Number of Beeps Signal Strength Result
3 8 to 10 Strong signal
2 5 to 7 Average signal
1 1 to 4 Weak signal (relocate)
Worksheet 11: Zone Report Codes
Section Zone
Alarm
Report
Codes
Alarm
Restore
Report Codes
Tam per
Report
Codes
Tam per
Restore
Report Codes
Section Zone
Alarm
Report
Codes
Alarm
Restore
Report Codes
Ta mp er
Report
Codes
Ta mp er
Restore
Report Codes
[141]
1 ___/___ ___/___ ___/___ ___/___
[157]
17 ___/___ ___/___ ___/___ ___/___
[142]
2 ___/___ ___/___ ___/___ ___/___
[158]
18 ___/___ ___/___ ___/___ ___/___
[143]
3 ___/___ ___/___ ___/___ ___/___
[159]
19 ___/___ ___/___ ___/___ ___/___
[144]
4 ___/___ ___/___ ___/___ ___/___
[160]
20 ___/___ ___/___ ___/___ ___/___
[145]
5 ___/___ ___/___ ___/___ ___/___
[161]
21 ___/___ ___/___ ___/___ ___/___
[146]
6 ___/___ ___/___ ___/___ ___/___
[162]
22 ___/___ ___/___ ___/___ ___/___
[147]
7 ___/___ ___/___ ___/___ ___/___
[163]
23 ___/___ ___/___ ___/___ ___/___
[148]
8 ___/___ ___/___ ___/___ ___/___
[164]
24 ___/___ ___/___ ___/___ ___/___
[149]
9 ___/___ ___/___ ___/___ ___/___
[165]
25 ___/___ ___/___ ___/___ ___/___
[150]
10 ___/___ ___/___ ___/___ ___/___
[166]
26 ___/___ ___/___ ___/___ ___/___
[151]
11 ___/___ ___/___ ___/___ ___/___
[167]
27 ___/___ ___/___ ___/___ ___/___
[152]
12 ___/___ ___/___ ___/___ ___/___
[168]
28 ___/___ ___/___ ___/___ ___/___
[153]
13 ___/___ ___/___ ___/___ ___/___
[169]
29 ___/___ ___/___ ___/___ ___/___
[154]
14 ___/___ ___/___ ___/___ ___/___
[170]
30 ___/___ ___/___ ___/___ ___/___
[155]
15 ___/___ ___/___ ___/___ ___/___
[171]
31 ___/___ ___/___ ___/___ ___/___
[156]
16 ___/___ ___/___ ___/___ ___/___
[172]
32 ___/___ ___/___ ___/___ ___/___
