Magellan / Spectra SP 23
PGMs Serial Number
To delete a wireless PGM, enter [000000] in its respective section.
To view the serial number display, refer to section [960].
For automatic assignment, press the PGM’s anti-tamper switch while in the respective section.
Refer to the Installer Quick Menu on page 3 for alternate PGM programming.
Wireless PGM Signal Strength
To view the wireless PGM signal strength, press the wireless PGM’s anti-tamper switch while in the respective section.
PGM Recognition
A Wireless PGM module can be assigned to any PGM. It will work in parallel with the Control Panel Output.
Section Wireless PGM Serial Number Section Wireless PGM Serial Number
[301] PGM 1: ____/____/____/____/____/____ [309] PGM 9: ____/____/____/____/____/____
[302] PGM 2: ____/____/____/____/____/____ [310] PGM 10: ____/____/____/____/____/____
[303] PGM 3: ____/____/____/____/____/____ [311] PGM 11: ____/____/____/____/____/____
[304] PGM 4: ____/____/____/____/____/____ [312] PGM 12: ____/____/____/____/____/____
[305] PGM 5: ____/____/____/____/____/____ [313] PGM 13: ____/____/____/____/____/____
[306] PGM 6: ____/____/____/____/____/____ [314] PGM 14: ____/____/____/____/____/____
[307] PGM 7: ____/____/____/____/____/____ [315] PGM 15: ____/____/____/____/____/____
[308] PGM 8: ____/____/____/____/____/____ [316] PGM 16: ____/____/____/____/____/____
Section Section
[321] PGM 1 Wireless PGM Signal Strength [329] PGM 9 Wireless PGM Signal Strength
[322] PGM 2 Wireless PGM Signal Strength [330] PGM 10 Wireless PGM Signal Strength
[323] PGM 3 Wireless PGM Signal Strength [331] PGM 11 Wireless PGM Signal Strength
[324] PGM 4 Wireless PGM Signal Strength [332] PGM 12 Wireless PGM Signal Strength
[325] PGM 5 Wireless PGM Signal Strength [333] PGM 13 Wireless PGM Signal Strength
[326] PGM 6 Wireless PGM Signal Strength [334] PGM 14 Wireless PGM Signal Strength
[327] PGM 7 Wireless PGM Signal Strength [335] PGM 15 Wireless PGM Signal Strength
[328] PGM 8 Wireless PGM Signal Strength [336] PGM 16 Wireless PGM Signal Strength
Signal Strength Indicator
8 to 10 / 3 beeps = Best signal 5 to 7 / 2 beeps = Average signal 1 to 4 / 1 beep = Weak signal (Relocate)
MG5000/SP5500 MG5050/SP6000/SP7000
PGM 1 Control Panel Output 1 Control Panel Output 1
PGM 2 Control Panel Output 2 Control Panel Output 2
PGM 3 N/A Control Panel Output 3
PGM 4 N/A Control Panel Output 4
PGM 5 N/A Control Panel Relay
PGM 6 ZX8 ID= 1 Output ZX8 ID= 1 Output
PGM 7 ZX8 ID= 2 Output ZX8 ID= 2 Output
PGM 8 ZX8 ID= 3 Output ZX8 ID= 3 Output
PGM 9 PGM4 Output 1 PGM4 Output 1
PGM 10 PGM4 Output 2 PGM4 Output 2
PGM 11 PGM4 Output 3 PGM4 Output 3
PGM 12 PGM4 Output 4 PGM4 Output 4
PGM 13 RTX3 Output 1 RTX3 Output 1
PGM 14 RTX3 Output 2 RTX3 Output 2
PGM 15 RTX3 Output 3 RTX3 Output 3
PGM 16 RTX3 Output 4 RTX3 Output 4
