DEVICE MAINTENANCE AND CLEANING
TRAINING
©Parata
Step Four: Reassemble Cutter Assembly
1. Reassemble using these instructions in reverse order.
Step Five: Return Cutter to Home Position
1. Return the cutter to the home position, align the red arrows, and turn locking knob to
secure the blade in place.
Note:
- Be sure to install the metal guard securely.
- When complete, align the cutter to the “Home Position” with the red arrows lined up.
- Check that the blade is locked forward in the Cut position (towards the rear of the machine,
and extended all the way forward in the blade holder)
- Check that the blade locking knob is tightened down securely.
