Parata ATP - Sliding Blade Holder Out of Cut-out

DEVICE MAINTENANCE AND CLEANING
TRAINING
59
©Parata
2014
How to Replace the TC Motor Assembly (ADMIN)
Required Materials
1 Phillips Head Screwdriver
1 TC Motor Assembly
1. Power off the ATP
2. Manually unlock ATP drawers by pulling the silver release knob.
2. Open the TC Drawer that contains the canister and the TC Motor Base Assembly that needs to
be replaced.
3. Remove the canister to expose the TC Motor Base.
