General facts Information Operation Help
-Freelycongurablecontrolelements-
7.2 10-button touchpad

The buttons on the 10-button touchpad can take over the
operation of the original secondary functions of the vehicle.
Function of the 10-button touchpad:
• The system (button signal or continuous signal) controls the
existing or subsequently installed vehicle components.
• Activating the indicator light (symbol) in the vehicle and on the
control element  (blue LED status light).
7.2.1 Function
Fig. 28: 10-button touchpad
Fig. 29: LED status light
