MSG11-5715-662 DCV UK.indd 21.07.22
Directly operated and pilot operated directional control valves
Series D1VW / D1DW / D3W / D3DW / D31DW / D41VW / D81VW / D91VW
16
Translation from German
Parker Hannin Corporation
Installation
strip 4 mm
Please order female connector M12x1 separately, order no.: 5004109
4
19.2 ...
28.8 V
2
0V
2
1
3
4
Wiring female connector
(View screw terminal connection)
