Directly operated and pilot operated directional control valves
Series D1VW / D1DW / D3W / D3DW / D31DW / D41VW / D81VW / D91VW
19
Translation from German
Parker Hannin Corporation
MSG11-5715-662 DCV UK.indd 21.07.22
Please note that with electrical connections the protective conductor (PE W) must be connected according to the
relevant regulations.
General
Design Directional spool valve
Actuation Solenoid
Series D31
Nominal size NG10
Weight (1/2 solenoids) [kg] 6.0 / 6.6
Mounting interface DIN 24340 A10
ISO 4401
NFPA D05
CETOP RP 121-H
Mounting position As desired, horizontal mounting preferred
Ambient temperature [°C] -20...+60
Hydraulic
Max. operating pressure [bar] Pilot drain internal: P, A, B, X: 350; T, Y: 140
Pilot drain external: P, A, B, T, X: 350; Y: 140
Fluid Hydraulic oil according to DIN 51524
Fluid temperature [°C] -20...+70
Viscosity permitted [cSt] / [mm²/s] 2.8...400
Viscosity recommended [cSt] / [mm²/s] 30...80
Max. contamination ISO 4406; 18/16/13
Flow max. [l/min] 150
Leckage at 350 bar (per ow path) [ml/min] to 100*
*depending on piston
Opening pressure of precharge valve [bar] n.a.
Min. pilot pressure [bar] 5
Static / Dynamic
Step response at 95 % [ms] Energized / De-energized:
DC solenoids pilot pressure 50 bar 60 / 40
100 bar 55 / 40
250 bar 55 / 40
350 bar 55 / 40
AC solenoids pilot pressure 50 bar 40 / 30
100 bar 35 / 30
250 bar 35 / 30
350 bar 35 / 30
Electrical
Duty cycle 100 % ED; CAUTION: coil temperature up to 150 °C possible
Protection class IP 65 to EN 60529 (plugged and mounted)
Code K J U G
Supply voltage [V] 12 V = 24 V = 98 V = 205 V =
Supply tolerance [%] ±10 ±10 ±10 ±10
Power consumption [A] 2.72 1.29 0.33 0.13
Power consumption [W] 32.7 31 31.9 28.2
Solenoid connection Connector to EN 175301-803, solenoid identication to ISO 9461
Wiring min. [mm²] 3 x 1,5 recommended
Wiring length max. [m] 50 recommended
Series D31DW
Technical data
