Directly operated and pilot operated directional control valves
Series D1VW / D1DW / D3W / D3DW / D31DW / D41VW / D81VW / D91VW
17
Translation from German
Parker Hannin Corporation
MSG11-5715-662 DCV UK.indd 21.07.22
General
Design Directional spool valve
Actuation Solenoid
Nominal size DIN NG06 / CETOP 03 / NFPA D03
Mounting interface DIN 24340 A6 / ISO 4401 / CETOP RP 121-H / NFPA D03
Mounting position As desired, horizontal mounting preferred
Ambient temperature [°C] -20...+60
Weight (1 solenoid) [kg] 1.8
Hydraulic
Max. operating pressure [bar] P, A B: 350 ; T: 210
Fluid Hydraulic oil according to DIN 51524
Fluid temperature [°C] -20...+70
Viscosity permitted [cSt] / [mm²/s] 2.8...400
Viscosity recommended [cSt] / [mm²/s] 30...80
Max. contamination ISO 4406; 18/16/13
Flow max. [l/min] 80
Leakage at 50 bar [ml/min] Up to 10 per ow path, depending on piston
Static / Dynamic
Step response at 95 % [ms] Energized: 32 ; De-energized: 40
Electrical
Duty cycle 100 % ED; CAUTION: coil temperature up to 150 °C possible
Max. switching frequency [1/h] 15000
Protection class IP 65 to EN 60529 (plugged and mounted)
Code K J U G
Operating tolerance [V] 12 V = 24 V = 98 V = 205 V =
Supply tolerance [%] ±10 ±10 ±10 ±10
Power consumption [A] 2.72 1.29 0.33 0.13
Power consumption [W] 32.7 31 31.9 28.2
Solenoid connection Connector to EN 175301-803, solenoid identication to ISO 9461
Wiring min. [mm²] 3 x 1.5 recommended
Wiring length max. [m] 50 recommended
Please note that with electrical connections the protective conductor (PE W) must be connected according to the
relevant regulations.
Series D1VW / D1DW
Technical data
