Parker D1VW -SC Series Operating Instructions

Directly operated and pilot operated directional control valves
Series D1VW / D1DW / D3W / D3DW / D31DW / D41VW / D81VW / D91VW
23
Translation from German
Parker Hannin Corporation
MSG11-5715-662 DCV UK.indd 21.07.22
Connection to EN 175301-803, DC solenoid, with connector M12x1
*,
Designs B, E, F
* Please order female connector M12x1 separately, order no.: 5004109
The space necessary to remove the plug per EN 175301-803, design type AF is at least 15 mm.
The torque for the screw M3 of the plug has to be 0.5 to 0.6 Nm.
Designs H, K, M
Surface nish
Kit
Kit
0,01/100
R
63.
max
BK385
4x M6x40
ISO 4762-12.9
13.2 Nm
±15 %
NBR: SK-D3W-30
FPM: SK-D3W-V30
114
70
Ø11
30
BA
Ø6.8
124
292.5
Ø42
322
114
70
Ø11
30
BA
Ø6.8
178
292.5
Ø42
322
Series D3W / D3DW
No dened position for
female connector
No dened position for
female connector
