Parker D1VW -SC Series Operating Instructions

Directly operated and pilot operated directional control valves
Series D1VW / D1DW / D3W / D3DW / D31DW / D41VW / D81VW / D91VW
25
Translation from German
Parker Hannin Corporation
MSG11-5715-662 DCV UK.indd 21.07.22
Surface nish
Kit
Kit
0,01/100
R
63.
max
BK360
6x M12x75
ISO 4762-12.9
108 Nm
±15 %
NBR: SK-D81VW-N-91 / SK-D91VW-N-91
FPM: SK-D81VW-V-91 / SK-D91VW-V-91
230
300
76
Ø13.5
57
116
118
12
AB
AB
223*
130
The space necessary to remove the plug per EN 175301-803, design type AF is at least 15 mm.
The torque for the screw M3 of the plug has to be 0.5 to 0.6 Nm.
Series D81VW / D91VW
No dened po-
sition for female
connector
* Please order female connector M12x1 separately, order no.: 5004109
Connection to EN 175301-803, DC solenoid, with connector M12x1
*
