3.2. Motor characteristics and inverter association
The torque vs speed graph below explains different intrinsic values of the next tables.
0
20
40
60
80
100
120
140
160
180
0 1000 2000 3000 4000 5000 6000 7000 8000
Speed in rpm
Torque in N.m
Couple en N.m
Torque N.m
Mmax
Mo
Nmax
Constant Power
Flux Weakening
Nn ,Mn
Continuous Operating Area
Intermittent Operating Area
Rated Power
Rated
Torque
Rated
Speed
Max
Speed
Peak
Torque
