Parker HAS Series User Manual

Hydraulic and Electrohydraulic Actuators
HAS Series Analog Drives Manual
25
Parker Hannifin Corporation
Cylinder Division
Des Plaines, Illinois USA
www.parker.com/cylinder
Catalog HY08-4005-M3
WARNING: This product can expose you to chemicals including Lead and Lead Compounds which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
PROP 65 WARNING
WELCOME
SCREEN
MM
WWeellccoommee
SSccrreeeenn
Displays the software version of the unit
From the Welcome Screen, the display times-out (alternatively
you can press the key) to show the first of 4 menus:
OOppeerraattoorr
DDiiaaggnnoossttiiccss
QQuuiicckk SSeettuupp
SSeettuupp
SSyysstteemm
DIAGNOSTICS menu
at level 1
OPERATOR menu at
level 1
QUICK SETUP
menu at
level 1
SYSTEM menu at level 1
NNaavviiggaattiinngg tthhee MMeennuu SSyysstteemm
On power-up, the Keypad defaults into the OPERATOR menu,
timing out from the Welcome screen. You can skip the timeout
by pressing the
MM
key immediately after power-up which will
take you directly to the OPERATOR menu.
The menu system can be thought of as map which is navigated
using the four keys shown opposite.
Keys
EE
and
MM
navigate through the menu levels.
The up ( ) and down ( ) keys scroll through the Menu and
Parameter lists.
Refer to “The Menu System Map” to see how the full menu is mapped.
scroll
scroll
exit to
previous
menu
next
menu
E
M
A view of HAS settings and diagnostic
parameters
A view of general diagnostic parameters
Not applicable for HAS Operation
Function blocks parameters drive
advanced configuration. Not
recommended for Alteration without
factory guidance
Application "save" and macro selection.
se s or other reprod
harm. For more information go to www.P65Warnings.ca.gov
PPaarrkkeerr HHaannnniiffiinn
CCoorrppoorraattiioonn
Cylinder Division
Des Plaines,
Illinois
22
wwwwww..ppaarrkkeerr..ccoo
mm/cylinder
SETUP menu at level 1
6901 Keypad
6901 Keypad Operation

Parker HAS Series Specifications

General

Output Voltage	0-Input Voltage
Control Modes	Torque, Speed
Feedback	Encoder, Tachometer
Operating Temperature	0°C to 40°C
Communication Interface	RS485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overtemperature
Enclosure	IP20
