Parker HAS Series - Hazard to Personnel; Application Risk

Hydraulic and Electrohydraulic Actuators
HAS Series Analog Drives Manual
3
Parker Hannifin Corporation
Cylinder Division
Des Plaines, Illinois USA
www.parker.com/cylinder
Catalog HY08-4005-M3
WARNING: This product can expose you to chemicals including Lead and Lead Compounds which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
PROP 65 WARNING
Safety
SSaaffeettyy
IIMMPPOORRTTAANNTT
Please read this information BEFORE installing the equipment.
AApppplliiccaattiioonn RRiisskk
The specifications, processes and circuitry described herein are for guidance
only and may need to be adapted to the user's specific application.
Parker Hannifin Manufacturing Limited does not guarantee the suitability of the
equipment described in the Manual for individual applications.
This manual is for anyone
installing, operating and
servicing this unit.
Hybrid Actuation System Cylinders
Series HAS 500
Catalog HY08-
Safety
WARNING: This product can expose you to chemicals including Lead and Lead Compounds which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
PROP 65 WARNING
Parker Hannifin Corporation
Cylinder Division
Des Plaines, Illinois
2
www.parker.com/cylinder
•
WARNING!
This equipment can endanger life through rotating machinery and high voltages. Failure to observe
the following will constitute an ELECTRICAL SHOCK HAZARD.
Metal parts may reach a temperature of 70 degrees Centigrade in operation.
Before working on the equipment, ensure isolation of the main supply from terminals L1, L2 and
L3. The equipment contains high value capacitors which discharge slowly after removal of the main
supply. Wait for a least 3 minutes for the dc link terminals (DC+ and DC-terminal voltage with a
meter to confirm that the voltage is less than 50V.
do not apply external voltage sources (main supply or otherwise to any of the braking terminals
(DBR+, DBR-, DC+, INT or EXT)
Hazard to Personnel
Application Risk
The specifications, processes and circuitry described herein are for guidance only and may need to be
adapted to user’s specific application.
Parker Hannifin Manufacturing Limited does not guarantee the suitability of the equipment described in
the manual for individual applications.
This manual is for
anyone installing,
operating and
servicing this unit.
You must be technically
competent to install and
operate this unit.
Before working on the unit,
isolate the main supply
from terminals L1, L2 and
L3 and wait 3 minutes
Disconnect the unit from
circuits when doing high
voltage resistance checks.
The unit must be
permanently earthed
due to high earth
leakage current
The drive motor must be
connected to an
appropriate safety earth.
Electrostatic discharge
sensitive parts: observe
static control precautions.
Copy existing 890
parameters to any
replacement 890 unit.
Safety
