7.4 Mains connection Power module PSD1-M_P020 with line choke
Increased power by means of a line choke
Category
Specifications
PSD1-M_P020 with line
choke
230 V
400 V
480 V
Mains voltage
230 VAC ±10 % 50-60 Hz
400 VAC ±10 % 50-60 Hz
480VAC ±10% 50-60Hz
Rated voltage
3 AC 230 V
3 AC 400 V
3 AC 480 V
Input Current [rms]
44 A
44 A
40 A
Output voltage
325 VDC ±10 %
565 VDC ±10 %
680 VDC ±10 %
Output power
15.5 kW
27 kW
30 kW
Pulse power (<5 s)
31 kW
54 kW
60 kW
Power dissipation
140 W
140 W
140 W
Maximum fuse rating per
device
2 fuses in line are required
Measure for line protection:
MCB (K characteristic) with a rating of 50A / 4xxVAC (depending on the input
voltage)Recommendation:
Recommendation: (ABB) S203U-K50 (440VAC)
Measure for device protection:
Fuses 80A / 700VAC per supply leg in accordance with UL category JFHR2:
Essential: Bussmann 170M1366 or 170M1566D
Earth leakage current
Current on the mains PE (>3,5 mA)
Supply networks
Possible supply networks: TN
The specified performance data are only valid in connection with line choke IND-0002-01
or IND-0002-02 (UL).
7.5 Environmental requirements PSD1
Category
Specification
General ambient conditions
In accordance with EN 60 721-3-3
Climate (temperature/humidity/barometric pressure): Class 3K22
Permissible ambient
temperatures:
Operation
0 to +40 °C Class 3K22
Storage
-25 to +70 °C
Transportatio
n
-25 to +70 °C
Tolerated humidity:
Operation
<= 85% Class 3K22
Storage
<= 95 %
Transport
<= 95 %
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load ratings
<=2000m above sea level for 1% / 100m power reduction
>2000m above sea level likewise with 1% / 100m power reduction but without UL & CE
certification
Sealing
IP20 protection level in accordance with EN 60 529
Mechanical vibrations:
With packaging (transport/ storage): 10 m/s
2
; 9 – 200 Hz
Without packaging: 10 m/s
2
; 57 – 150 Hz
Pollution degree
Pollution degree 2 in accordance with EN 60664-1 and EN 61800-5-1
