Page 10 – SD-453
Figure U - Sensor check (Pressure and temperatures appear proper for system)
(See Step 10)
Figure V - Proof of work. Save baseline data for each coil, case, etc...
(See Step 11)

Click here

This needs to
be within a
3°F dead band

This needs to
be within a
2°F dead band

Click here to adjust how
much history you would
like to capture

Click here to
create CSV
