Parker Sporlan Subcool Control - APPENDIX N - 10 K Temperature Sensor Specifications

Bulletin 100-50-5.2 – Page 21
APPENDIX N - 10K Temperature Sensor Specifications
°C °F RANGE VDC
-51.1 -60 4.949 - 4.956
-50.6 -59 4.947 - 4.954
-50.0 -58 4.945 - 4.952
-49.4 -57 4.942 - 4.950
-48.9 -56 4.940 - 4.948
-48.3 -55 4.938 - 4.946
-47.8 -54 4.936 - 4.944
-47.2 -53 4.933 - 4.942
-46.7 -52 4.931 - 4.939
-46.1 -51 4.928 - 4.937
-45.6 -50 4.925 - 4.935
-45.0 -49 4.922 - 4.932
-44.4 -48 4.919 - 4.929
-43.9 -47 4.916 - 4.927
-43.3 -46 4.913 - 4.924
-42.8 -45 4.910 - 4.921
-42.2 -44 4.906 - 4.918
-41.7 -43 4.903 - 4.915
-41.1 -42 4.899 - 4.911
-40.6 -41 4.895 - 4.908
-40.0 -40 4.892 - 4.905
-39.4 -39 4.887 - 4.902
-38.9 -38 4.884 - 4.898
-38.3 -37 4.879 - 4.894
-37.8 -36 4.875 - 4.890
-37.2 -35 4.871 - 4.886
-36.7 -34 4.866 - 4.882
-36.1 -33 4.861 - 4.878
-35.6 -32 4.856 - 4.873
-35.0 -31 4.851 - 4.869
-34.4 -30 4.846 - 4.864
-33.9 -29 4.841 - 4.859
-33.3 -28 4.835 - 4.854
-32.8 -27 4.830 - 4.849
-32.2 -26 4.824 - 4.844
-31.7 -25 4.818 - 4.839
-31.1 -24 4.812 - 4.833
-30.6 -23 4.805 - 4.827
-30.0 -22 4.799 - 4.821
-29.4 -21 4.792 - 4.816
-28.9 -20 4.785 - 4.809
-28.3 -19 4.778 - 4.802
-27.8 -18 4.771 - 4.796
-27.2 -17 4.763 - 4.789
-26.7 -16 4.756 - 4.782
-26.1 -15 4.748 - 4.775
-25.6 -14 4.739 - 4.768
-25.0 -13 4.731 - 4.760
-24.4 -12 4.722 - 4.753
-23.9 - 11 4.714 - 4.744
-23.3 -10 4.705 - 4.736
-22.8 -9 4.696 - 4.728
-22.2 -8 4.686 - 4.719
-21.7 -7 4.677 - 4.710
-21.1 -6 4.667 - 4.701
-20.6 -5 4.656 - 4.692
-20.0 -4 4.646 - 4.682
-19.4 -3 4.635 - 4.673
-18.9 -2 4.625 - 4.662
-18.3 -1 4.613 - 4.652
-17.8 0 4.602 - 4.642
°C °F RANGE VDC
-17.2 1 4.590 - 4.631
-16.7 2 4.579 - 4.620
-16.1 3 4.566 - 4.608
-15.6 4 4.552 - 4.598
-15.0 5 4.540 - 4.585
-14.4 6 4.527 - 4.574
-13.9 7 4.514 - 4.561
-13.3 8 4.500 - 4.547
-12.8 9 4.487 - 4.535
-12.2 10 4.472 - 4.522
-11.7 11 4.459 - 4.509
-11.1 12 4.443 - 4.495
-10.6 13 4.427 - 4.481
-10.0 14 4.412 - 4.466
-9.4 15 4.396 - 4.453
-8.9 16 4.381 - 4.437
-8.3 17 4.364 - 4.421
-7.8 18 4.348 - 4.406
-7.2 19 4.330 - 4.390
-6.7 20 4.314 - 4.374
-6.1 21 4.296 - 4.357
-5.6 22 4.277 - 4.341
-5.0 23 4.260 - 4.324
-4.4 24 4.240 - 4.307
-3.9 25 4.223 - 4.288
-3.3 26 4.203 - 4.270
-2.8 27 4.185 - 4.252
-2.2 28 4.164 - 4.233
-1.7 29 4.145 - 4.215
-1.1 30 4.124 - 4.195
-0.6 31 4.102 - 4.177
0.0 32 4.082 - 4.156
0.6 33 4.060 - 4.137
1.1 34 4.040 - 4.115
1.7 35 4.017 - 4.093
2.2 36 3.996 - 4.074
2.8 37 3.972 - 4.051
3.3 38 3.951 - 4.031
3.9 39 3.927 - 4.008
4.4 40 3.902 - 3.987
5.0 41 3.880 - 3.963
5.6 42 3.855 - 3.942
6.1 43 3.832 - 3.917
6.7 44 3.807 - 3.893
7. 2 45 3.784 - 3.870
7. 8 46 3.758 - 3.845
8.3 47 3.734 - 3.823
8.9 48 3.707 - 3.797
9.4 49 3.680 - 3.774
10.0 50 3.655 - 3.748
10.6 51 3.628 - 3.724
11. 1 52 3.603 - 3.696
11. 7 53 3.576 - 3.669
12.2 54 3.550 - 3.645
12.8 55 3.522 - 3.618
13.3 56 3.497 - 3.593
13.9 57 3.468 - 3.565
14.4 58 3.438 - 3.540
15.0 59 3.412 - 3.511
15.6 60 3.383 - 3.486
16.1 61 3.357 - 3.456
°C °F RANGE VDC
16.7 62 3.327 - 3.427
1 7. 2 63 3.301 - 3.401
1 7. 8 64 3.271 - 3.372
18.3 65 3.244 - 3.346
18.9 66 3.214 - 3.316
19.4 67 3.183 - 3.289
20.0 68 3.156 - 3.260
20.6 69 3.125 - 3.233
21.1 70 3.098 - 3.202
21.7 71 3.067 - 3.171
22.2 72 3.040 - 3.144
22.8 73 3.009 - 3.114
23.3 74 2.982 - 3.086
23.9 75 2.951 - 3.056
24.4 76 2.919 - 3.028
25.0 77 2.891 - 2.998
25.6 78 2.861 - 2.970
26.1 79 2.833 - 2.938
26.7 80 2.802 - 2.907
27.2 81 2.774 - 2.880
27.8 82 2.744 - 2.849
28.3 83 2.716 - 2.821
28.9 84 2.685 - 2.790
29.4 85 2.653 - 2.763
30.0 86 2.626 - 2.732
30.6 87 2.595 - 2.704
31.1 88 2.568 - 2.673
31.7 89 2.538 - 2.642
32.2 90 2.510 - 2.614
32.8 91 2.480 - 2.584
33.3 92 2.453 - 2.556
33.9 93 2.423 - 2.526
34.4 94 2.392 - 2.499
35.0 95 2.365 - 2.469
35.6 96 2.336 - 2.442
36.1 97 2.309 - 2.411
36.7 98 2.280 - 2.381
37.2 99 2.253 - 2.354
37.8 100 2.224 - 2.324
38.3 101 2.198 - 2.298
38.9 102 2.170 - 2.269
39.4 103 2.140 - 2.242
40.0 104 2.115 - 2.213
40.6 105 2.086 - 2.188
41.1 106 2.061 - 2.158
41.7 107 2.034 - 2.129
42.2 108 2.009 - 2.104
42.8 109 1.981 - 2.076
43.3 110 1.957 - 2.051
43.9 111 1.930 - 2.023
44.4 11 2 1.902 - 1.998
45.0 11 3 1.878 - 1.971
45.6 114 1.852 - 1.947
46.1 11 5 1.829 - 1.919
46.7 11 6 1.803 - 1.892
47.2 11 7 1.780 - 1.868
47.8 11 8 1.754 - 1.842
48.3 119 1.732 - 1.819
48.9 120 1.707 - 1.793
49.4 121 1.681 - 1.770
50.0 122 1.659 - 1.745
°C °F RANGE VDC
50.6 123 1.635 - 1.722
51.1 124 1.614 - 1.697
51.7 125 1.590 - 1.672
52.2 126 1.569 - 1.650
52.8 127 1.546 - 1.626
53.3 128 1.525 - 1.605
53.9 129 1.503 - 1.581
54.4 130 1.479 - 1.560
55.0 131 1.459 - 1.537
55.6 132 1.438 - 1.517
56.1 133 1.418 - 1.493
56.7 134 1.397 - 1.471
57.2 135 1.378 - 1.451
57.8 136 1.357 - 1.429
58.3 137 1.338 - 1.410
58.9 138 1.318 - 1.389
59.4 139 1.297 - 1.370
60.0 140 1.279 - 1.349
60.6 141 1.260 - 1.330
61.1 142 1.242 - 1.309
61.7 143 1.223 - 1.289
62.2 144 1.206 - 1.272
62.8 145 1.187 - 1.252
63.3 146 1.171 - 1.235
63.9 147 1.153 - 1.216
64.4 148 1.134 - 1.199
65.0 149 1.118 - 1.180
65.6 150 1.101 - 1.164
47.8 11 8 1.754 - 1.842
48.3 119 1.732 - 1.819
48.9 120 1.707 - 1.793
49.4 121 1.681 - 1.770
50.0 122 1.659 - 1.745
50.6 123 1.635 - 1.722
51.1 124 1.614 - 1.697
51.7 125 1.590 - 1.672
52.2 126 1.569 - 1.650
52.8 127 1.546 - 1.626
53.3 128 1.525 - 1.605
53.9 129 1.503 - 1.581
54.4 130 1.479 - 1.560
55.0 131 1.459 - 1.537
55.6 132 1.438 - 1.517
56.1 133 1.418 - 1.493
56.7 134 1.397 - 1.471
57.2 135 1.378 - 1.451
57.8 136 1.357 - 1.429
58.3 137 1.338 - 1.410
58.9 138 1.318 - 1.389
59.4 139 1.297 - 1.370
60.0 140 1.279 - 1.349
60.6 141 1.260 - 1.330
61.1 142 1.242 - 1.309
61.7 143 1.223 - 1.289
62.2 144 1.206 - 1.272
62.8 145 1.187 - 1.252
63.3 146 1.171 - 1.235
63.9 147 1.153 - 1.216
64.4 148 1.134 - 1.199
65.0 149 1.118 - 1.180
65.6 150 1.101 - 1.164
