Parsun F40 EFI User Manual

10
Measurement conditions:
Unless otherwise specified, the ambient temperature is 20℃ during measurement.
Charging system
Item
Data
Item
Data
Ligh
ting
Coil
Outp
ut
peak
volta
ge
Start (no-load)
14.0 V
Fuse
30 A
1500 r/min (no-load)
45.0 V
Output
peak
voltage of
rectifier
regulator
1500 r/min (no-load)
13.0 V
3500 r/min (no-load)
102.0 V
3500 r/min (no-load)
13.0 V
Resistance
0.561～0.759 Ω
Seating torque
Specified torque
Mounting position
Name
Thread
specificati
on
Torque
Engi
ne
Spark plug
-
-
18 Nm
Flywheel
Nut
M20
157 Nm
Cylinder cover
Frist tightening
Bolt
M9
23 Nm
Second tightening
47 Nm
Frist tightening
Bolt
M6
6 Nm
Second tightening
12 Nm
Oil filter
-
-
18 Nm
Oil filter stud
-
-
40 Nm
Lock nut (rocker arm)
Nut
M6x0.75
13.5Nm
Engine assembly
Bolt
M8
21 Nm
Exhaust
cover plate
Frist tightening
Bolt
M6
6 Nm
Second tightening
12 Nm
Thermostat cover
Bolt
M6
7Nm
Crankcase
Frist tightening
Bolt
M8
15 Nm
Second tightening
30 Nm
Frist tightening
Bolt
M6
6 Nm
Second tightening
12 Nm
Continued：
Mounting position
Name
Thread
specification
Torque
Engine
Connecting
rod
Frist tightening
Bolt
M6
6 Nm
Second
tightening
17 Nm
Driven pulley
Bolt
M10
38 Nm
Underwater
unit
Underwater unit assembly
Bolt
M10
40 Nm
Bolt
M8
40 Nm
Water intake
Screw
M5
1 Nm
Oil drain bolt
Bolt
-
9 Nm
Oil inspection hole
Bolt
-
9 Nm
