1． Remove handle bracket, shift handle and steering handle.
2． Remove the throttle push-pull cable assembly.
3． Remove the cotter pin and remove the resistance adjustment knob.
4． Remove the throttle grip.
5． Remove throttle retaining plate and throttle lever.
6． Remove the engine emergency stop switch.
7． Check whether the shift linkage is bent and deformed. Replace it if necessary.
8． Check the steering handle for cracks or damage. Replace it if necessary.
9． Check the handle anti-wear ring and wave washer for cracks or damage. Replace it
if necessary.
10．Check whether the cable in the throttle push-pull cable assembly is worn or broken.
Replace it if necessary.
11．Check whether the throttle lever is bent or damaged. If yes, replace it.
12．Check the conductivity of engine emergency stop switch ; If it does not conform to
the standard, replace it.
Remove the locking plate: Conducting
Install locking plate: Non-conducting
Press the switch button: Conducting
Water unit and bracket
