21
3. Sleeve the adjusted push-pull cable joint into the fixed column, install the clip clutch
and tighten the lock nut.
Shift operation
When shifting from neutral to forward or backward, check the smoothness of shift operation.
Adjust the columnar nut if necessary.
Underwater unit
Gear oil
Check the amount of gear oil:
Remove the oil level plug screw, if there is gear oil overflow, the oil amount is correct; If there is no
overflow of oil, add gear oil.
1. Oil level plug screw
Replace gear oil
1. Position the outboard motor vertically.
2. Place a container with sufficient capacity under the outboard motor.
3. Remove the oil drain screw, and then remove the oil level plug screw; Drain gear oil.
1. Oil level plug screw 2. Oil drain screw
4. Use the pressure filling device to inject gear oil into the oil drain screw hole.
5. When gear oil overflows from the oil level plug hole, install the oil level plug screw.
6. Install the oil drain screw; Wipe off the spilled gear oil.
Note:
Check the discharged gear oil. If the gear oil is emulsified, check the seal and replace the
oil seal if necessary; If the gear oil contains metal debris, check the gears and bearings.
Note:
A new drain plug gasket must be replaced every time.
Air tightness inspection of underwater unit
Connect the leak detection device to the oil level plug hole to detect the air tightness of the
underwater unit. If the pressure drops (the pressure is 1kg/cm
3
), check the oil seal and
other components.
General maintenance
Anode
