PAGE 30
DISPLAY AVAILABLE FACTORY YOUR
STEP DESCRIPTION CODE SETTINGS SETTING SETTING
19 Profile Time Base Ptb 1=HHH.T - Hours & Tenths
3
2=HH.MM - Hours & Min.
3=MM.SS - Minutes & Sec.
EO Option
4=Units/Hr ramp rate;
Hrs. & Tenths soak time
5=Units/Hr ramp rate;
Hrs/Mins soak time
6=Units/Hr ramp rate;
Mins & Secs soak time
20 Profile Interrupt Action PiA 0=Go to Off mode
1
1=Continue profile
2=Go into hold condition
3=Restart at the beginning
of the profile
21 Remote Run/Hold rrH 0=Not selected
0
1=Selected. Remote
Run/Hold will override
controller front panel
when placed in hold
from remote source
2=Selected. Remote
Run/Hold will not
override controller
front panel when placed
in hold from remote source
22 Process Filter Factor PFF 1 to 20 (# of scans aver.)
1
1=No filtering
23 Display Filter Factor dFF 1 to 20 (# of scans aver.)
1
1=No filtering
Parameters 24 - 28 are for Extended Option (EO) Only
24 Current Output 1 Range Co1r 0=0 to 20 mA
1
1=4 to 20 mA
25 Current Output 2 Range Co2r 0=0 to 20 mA
1
1=4 to 20mA
26 Process Output Pout 0=Not selected
0
1=Process Assigned to
Current Output 1
2=Process Assigned to
Current Output 2
3=Setpoint Assigned to
Current Output 1
4=Setpoint Assigned to
Current Output 2
27 Process/Setpoint Pou -9999 to 9999
2000
Output Upper Value
28 Process/Setpoint PoL -9999 to 9999
0
Output Lower Value
To Next Page
