Identifying components
This section describes the parts and connectors on the machine.
Front-right view
1 52
Figure 1.2 Front-right view
Component Description
1 Power Button
2 12.1-inch TFT LCD; 5-wire Resistive touch
3 IO Panel
4 LED Power Indicator
5 Triple-track MSR
