Partner PT-6212 - Mainboard Connectors; Figure 4.3 PT-6212 Mainboard Connectors

49
PT-6212 mainboard connectorsFigure 4.3
Mainboard connectors
connector to
LCD panel
connector to
speaker
connector
to thermal
printer
connect to
touch panel
connect to
HDD power
connector to
MSR
connector
to power
button
connector to
power LED
connect to SATA
HDD
connector
to customer
display
connector to
inverter
connector to
COM4
battery
