I/O connectors
Figure 1.4 PT-6212 I/O connectors
5
21 3 4
6 7 8 9 10
Connector Description
1 COM4 port
2 COM3 port
3 COM2 port
4 LAN port (RJ-45)
5 12V power connector
6 PS/2 keyboard port
7 RJ-11 cash drawer port
8 VGA port
9 COM1 port
10 USB ports
