Mainboard jumper
JCMOS
JLV1JLV2
Figure 4.2 SP-800 mainboard jumper
Jumper Setting Description
JCMOS
1-2 closed (default) Normal
2-3 closed Clear CMOS
1
1 1
JP2
1
5
2
6
JP3
1
5
2
6
