Partner SP-800 - COM4 Port and PS;2 Port; I;O Shield

52 C H A P T E R 5 R E P L A C I N G F I E L D R E P L A C E A B L E U N I T S ( F R U s )
COM4 port and PS/2 Port
Before proceeding, remove the
following FRUs.
• “Back Cover” on page 50.
1. Remove four screws.
2. Remove the COM4 port and
PS/2 port.
I/O Shield
Before proceeding, remove the
following FRUs.
• “Back Cover” on page 50.
• “COM4 port and PS/2 port”
on page 52.
1. Remove all screws from the
I/O panel.
2. Remove four screws from
the I/O shield.
3. Remove the I/O shield.
