Partner SP-800 - Panel Bracket

55
3. Remove three screws.
4. Remove all cables from the
inverter.
5. Remove the inverter.
When replacing:
Put the inverter in the plastic
cover before replacing it.
Panel Bracket
Before proceeding, remove the
following FRUs.
• “Back Cover” on page 50.
• “Speaker” on page 61.
• “Power Button” on page 61.
• “COM4 port and PS/2 port”
on page 52.
• “I/O Shield” on page 52.
• “Mainboard” on page 54.
• “Inverter” on page 54.
1. Remove four screws.
2. Remove the panel bracket.
