Partner SP-800 - IO Panel Cover; Stand Base Back Cover

48 C H A P T E R 5 R E P L A C I N G F I E L D R E P L A C E A B L E U N I T S ( F R U s )
IO Panel Cover
1. Flip up the LCD panel
2. Remove the screw from the IO
panel cover and remove the cover.
Stand Base Back Cover
1. Remove two screws.
2. Remove the stand base back
cover.
