23
Fig. 11: Pulling out the EPP foam cover of the filters and heat exchanger
5. Holding them by the strap, pull the filters E out of the filter compartments.
Fig. 12: Pulling out the filters
6. On the filter frame of each filter, there is an arrow to indicate the prescribed direction of flow. Insert the new
filters according to their designated direction of flow F.
