13.1.2 Multi-functional base Box
The dimensions of a L920 Multi-functional base box are 7.25 in x 6 in x 7.75 in (18.4 cm x 15.24 cm x
19.68 cm). A multi-functional base box weighs approximately 2.3 lbs. (.9 kg).
Please note there are labels with the part number and serial number of the L920 affixed to the outside
of the box. You can retain the original boxes in case the unit needs to be returned to PAX for service.
Part number, revision number and serial number labels for the L920 are
affixed to the underside of the L920 unit.
