Connecting Ethernet and Power
Please connect the Ethernet cable to the pinpad before connecting the power.
1. On the back of the Pinpad all interfaces are
color coded.
Note: Only LAN1 is supported at this time
2. Please connect the Ethernet Cable to the
LAN1 Port (RED).
3. Location the power cord and adaptor.
Connect the power cord to the adaptor
4. Connect one end to your outlet/surge
protector and connect the other end to the
Power Port (Green).
