5 | P a g e
6. Connect an Ethernet cable
(with internet) to the port on
the data/power cable that
says “LAN”. (The other 2
connections are not used.)
7. This is what your set up should
look like when everything is
properly connected.
8. Replace the back cover making
sure to properly align the
cable grommet into the
channel.
