Alarm
L-Audio-R1
Group 1 of RCA audio left and right outputs port
L-Audio-R2
Group 2 of RCA audio left and right outputs port
Audio 1
AES/EBU and Balance Audio output port 1 (A special DB-9 conversion cable is
offered as accessory)
Audio 2
AES/EBU and Balance Audio output port 2 (A special DB-9 conversion cable is
offered as accessory)
TUNER OUT
Tuner signal loop through output port
TUNER IN
Tuner signal input
SWITCH
AC Power supply switch
Control
RJ-45 Ethernet port for equipment control and supervision
Control
USB port for firmware upgrade
SDI 2
SD or HD Serial Digital Video output port 2
SDI 1
SD or HD Serial Digital Video output port 1
HDMI
High Definition Multimedia Interface output port
CVBS
CVBS RCA video output port
Grounding terminal
POWER SOCKET
AC 90~250V 50-60Hz input
4.3 RS-232 Serial Port
The RS-232 port is used for equipment software debug use, its pin definition is shown in the table.
The parameter settings are:
● No Parity bit
● 38400 Bauds
● 8 data bits
● 1 Stop bit
Pin Pin Function
1
N.C.
2
TXD
3
RXD
4 N.C.
5 GND
6
N.C.
7
N.C.
