 PCM audio output on two AES/EBU audio output ports
 On Site software update through IP
 RSSI, received Eb/No & BER monitoring
3. Technical Specifications
Tuner Input
DVB-S/S2 Tuner Input (ISI Factory Optional)
1×F type female 75Ω for Input, 1×F type
Connector Type
female 75Ω for loop through output
Input Frequency Range 950 ~ 2150MHz
Input Level -25 ~ -65dBm
Symbol Rate 2 ~ 45MBaud
DVB-S QPSK: 0.35
Roll-off Factor
DVB-S2 8PSK: 0.35, 0.25, 0.2
DVB-S QPSK: 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2 QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9,9/10
FEC Code Rate
DVB-S2 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
LNB Polarity Selection
Voltage
0, 13V, 18V selectable
LNB Band Selection Tone 0/22KHz selectable
Satellite Selection Command DiSEqC 1.0
ISI ID 1 ~ 255 user configurable
DVB-C Tuner Input
Connector Type
1×F type female 75Ω for Input, 1×F type female 75Ω for loop
through output
Input Frequency Range 51 ~ 862MHz
Input Level 51 ~ 75dBµV
Symbol Rate 1 ~ 7MBaud (ITU J.83 Anne× A)
Constellation 16QAM, 32QAM, 64QAM, 128QAM, 256QAM
Bandwidth 6MHz, 7MHz, 8MHz
Input Return Loss 7dB (typ.)
