8
N.C.
9
N.C.
4.4 Audio DB-9 Port
DCH-5200P uses a special DB-9 port for AES/EBU and balanced Audios. Pins are defined in below Table.
Pin Pin Function
1
AES Audio (+)
2
AES Audio Ground
3
Left Channel (-)
4 Right Channel (-)
5 Right Channel Ground
6
AES Audio (-)
7
Left Channel Ground
8
Left Channel (+)
9
Right Channel (+)
4.5 Management Ethernet Port
The Management port is used to remote control and supervise the equipment through IP, it’s also for the software
update. Its factory setting is as following:
 IP address:10.10.70.48
 Sub Mask:255.255.255.0
 Gateway:10.10.70.1
Both web based control software and proprietary HDMS software are using this port.
Notice: When apply default setting to DCH-5200P, the above settings for IP will not be affected, this is for
maintaining the connectivity of the unit to the IP Network.
