4.6 TS over IP Ethernet Port
The TS over IP port is an option by adding the daughter board inside the rack. The default setting is as following:
IP address:10.10.10.10
2
nd
IP address: 10.10.10.20 (for option DCH-5100P-32x, if equipped)
Sub Mask:255.255.255.0
Gateway:10.10.10.1
Depending on the option selected by the customer, this TS over IP port is either 10/100 Base-T or 100/1000
Base-T compliant to the IEEE 802.3 specifications.
5. Operation
5.1 Local Control
5.1.1 Getting Started
After successful installation and connection of the Professional IRD Processor DCH-5200P, switch on the power
supply. The equipment will check the hardware and software versions, then the product name and its IP address
will be shown in the LCD screen.
The IP address of the equipment can be changed in the System menu. Go into the Local Setup submenu, user
can set IP address, network mask and IP gateway, press ENTER to select the option, and use LEFT or RIGHT to
move the cursor between digits and use UP or DOWN to change the value until the right value, then press
ENTER to make the selection.
