Submenu Name Description
LNB LO Frequency To configure the local oscillator frequency according to
the right satellite, its range is from 1000 to 26,500MHz.
Satellite Frequency To configure the satellite down link frequency according to
the right satellite, its range is from 1000 to 26,500MHz.
Symbol Rate To configure the symbol rate of QPSK signal, its range is
from 1000 to 45,000KBaud.
LNB Voltage To select the correct LNB voltage output from the F-
connector, user can choose between Off, 13V and 18V.
LNB 22KHz To activate the LNB 22KHz control signal to the LNB, user
can select between On and Off.
DiSEqC To configure the DiSEqC control, user can select Port A,
Port B, Port C, Port D or DiSEqC OFF.
PLS Gold Code To configure the PLS gold code, its range is from 0 to
262,141.
Freq Offset High To ensure the tuner locks the specific signal, its range is
from 1000K to 5,000KHz.
Tuner
Freq Offset Low To ensure the tuner locks the specific signal, its range is
from -5,000K to -1,000KHz. The condition is “Freq Offset
Low < Real IF - Setting IF < Freq Offset High”.
Source To configure the decoder source, user can select Tuner
Input, ASI-1 Input, ASI-2 Input, IP Input or Remux Input.
Program To configure which program should be decoded.
Video Output To configure the video properties, such as the screen
ratio, resolution, VBI issues and so on.
Audio Output To configure the audio properties, such as the audio PID,
output level and so on.
Mode To configure which program should be decoded when the
decoder source is changed, user can select between First
Service and Program Manual Selection.
Decoder
A/V Alarm Switch To enable or disable the A/V alarm, user can choose
between On and Off.
ASI-1
ASI-1 Source To select the ASI-1 output source.
ASI-2
ASI-2 Source To select the ASI-1 output source.
When set IP Board Type as Single IP input
TS over IP
Stream IP Address To configure the IP address of the TS over IP port.
