P550c Operation Manual
4 System assembly
www.pearpoint.com | 57
Cameras
The P354 and P356 have three high- resolution cameras, with PAL or NTSC versions available. All
cameras offer remote focus capabilities and use the latest ultra-bright LEDs for optimum lighting.
Cameras can be fitted direct to the crawler’s body (or to an elevator or lighthead). The cameras can only
be fitted in one alignment. A single 3mm Allen key screw is used to secure the camera to the crawler.
Connecting cameras
Cameras are connected using the C-clamp connection, the procedure is the same for all three cameras.
Fig. 4.9: Connecting a Forward View camera
