P550c Operation Manual
4 System assembly
www.pearpoint.com | 68
Crawler deployment tools
The crawler deployment tools for the P354 and P356
crawlers are optional accessories that allow you to safely
deploy and remove a crawler into manholes, culverts
and other access points. The deployment tools can
deploy and remove the crawler in conduits up to 16.5’ /
5m* deep.
*Using all 3 of the supplied poles.
Refer to page 167 for a guide to crawler deployment
4.2 Drums & External PSU
The external PSU connects to the manual drum using the link cable. The single end connects to the
manual drum and the split end terminals connect to the manual drum connection panel on the rear side
of the PSU’s handle.
Fig. 4.18: Deployment tool
