PEDROLLO E2 TRI - Mode 6 - Customised; Start-Up; Menu Access Commands

49
ENGLISH |
MODE 6 – CUSTOMISED
Customised mode (set up according to specic customer
needs)
With this mode, more expert customers are free to decide how to set
the electrical control panel operation by conguring the parameters
as they want.
Factory conguration
Parameter
to be congured
Value
RUN EMPTYING
SENS L OFF
IN1 RUN
IN2 RUN
LOGIC ALTERN.
DRY RUN EN OFF
DRY LOGIC COS
COSFI REC ON
REC TIME 2 min
MAX REC T 60 min
P1 3.0 bar
DP1 0.5 bar
START-UP
To avoid malfunctions due to setting up and operating the equipment incorrectly, read this manual
carefully and follow the instructions before putting the equipment into service.
Prime the pumps (lling and bleeding the air) before starting up the system.
After making all the electrical and plumbing connections correctly, enter the conguration menu to set the correct parame-
ter values for the kind of operation to be performed by the system.
MENU ACCESS COMMANDS
• Press the ON/OFF key to take the control panel OUT OF SERVICE (OFF)
• Press the + + keys simultaneously for 3 seconds
• Press the
or key to display the various set MENUS
The display will remain in this state for 1 minute, after which it will exit automatically if no other buttons have been
pressed. The backlighting of the programming menus will
