CONFIGURING THE INPUTS AND OUTPUTS
This menu is used to congure the control panel inputs and outputs. The type and operating range of the pressure transduc-
ers, the sensitivity of the capacitive level sensors and the external alarm input and output can be set.
• Open the menu
SELECT
INOUT CONFIG
• See PARAMETER EDITING COMMANDS for how to edit the values of each individual parameter.
SELECT
INOUT CONFIG
• Press the key to conrm the choice and enter the submenu
9
INOUT CONFIG
IN ALARM:ON
• Enable or disable the external alarm with acoustic and/or visual function.
• This alarm does not block electric pump operation, but signals a fault due to external
factors.
Default ON Range OFF–ON Step /
INOUT CONFIG
OUT ALARM:ON
• Enable or disable the relay output (NO/NC), to be used to power a siren and/or ash-
ing light.
Default ON Range OFF–ON Step /
INOUT CONFIG
LEVEL SENS:50
• Set the percentage sensitivity of the level sensor.
• This value should be calibrated for the conductivity of the water in the system.
Default 50% Range 1–100% Step 1%
INOUT CONFIG
P.TYPE:4-20mA
• Select the pressure transducer type:
– 4–20 mA amperometric
– 0–10 V ratiometric
Default 4–20 mA Range 4–20 mA / 0–10 V Step /
INOUT CONFIG
P.RANGE:16bar
• Select the maximum operating pressure of the pressure transducer.
Default 16 bar Range 10–40 Step 10/16/25/40

CONFIGURING THE CUSTOMISED PRESET MODE
This menu is used to choose the control panel automatic operating mode according to the requirements of the system to be
implemented.
You can choose from six dierent preset congurations
• Open the menu
SELECT
MODE CONFIG
• See PARAMETER EDITING COMMANDS for how to edit the values of each individual parameter.
