Operators Manual Model PT2000/H Series Gas Monitor Rev 2. January 2014
4.1 SystemParameters
This option sets the operating parameters of the system. Enable to disable options for
text messaging and setting Zone ID and Alarm Bypass Time Limit.
4.1.1. Site Name: A user defined Text field that will appear on the top right corner
of the Main Display Screen. This is to identify the location of the system when
sending out Alarm text messages over the mobile phone and when
downloading data logs.
4.1.2. Ethernet IP Address: IP Address needed to view data over internet or
address.
4.1.3. Active # of Relay Modules: If additional External Relay modules are used. This
option is valid only for Customer Application Programs that use the modules.
4.1.4. Alarm Bypass Time: Time in minutes that alarm will be bypassed / Inhibited
when the Alarm Bypass button is pressed on the main display screen.
